ATMEL AVR USBasp Programmer - China

https://www.ram-e-shop.com/web/image/product.template/6290/image_1920?unique=b20172c

175.00 EGP 175.0 EGP 175.00 EGP

175.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: PROG.AVR.SERIAL

Features:

  • Allows you to read or write the microcontroller EEPROM, firmware, fuse bits and lock bits
  • Support for Windows, Mac OS X and Linux
  • 5 KB/sec maximum write speed
  • Software controlled SCK option to support targets with low clock speed (< 1.5MHz)
  • 10 pin ISP interface (conforms to standard ISP 10-pin pinout)

The latest Window Drivers are fully signed, so you can use them on Windows Vista and above without any issues. The driver will work on both 32 and 64 bit platforms. On Linux And Mac OS X no kernel driver is required, just use AVRdude and specify the correct port. The programmer will work with a wide variety of Atmel AVR microcontrollers including the Atmega8a and Atmega168a. A full list is available on the specifications tab. The programmer will also work with a variety of software including

Included with the programmer is a 10 pin ISP cable, as shown in the main photo.
