Product Description
- High resolution: 128x64 (have the same resolution as 12864, high PPI)
- Large viewing angle: greater than 160° (a screen with the largest viewing angle in the monitor)
- Ultra-low power consumption: it's 0.06w in normal conditions (far less than TFT display)
- Wide voltage supply (3V~5V), 3.3V and 5V level logic compatible, no level shifter IC
- IIC interface and only requires 2 IOs to light up easily
- The range of working temperature is industrial (-20°C~70°C)
- Military-grade process standards, long-term work steadily
- Provide rich multi-platform routines and the technology support of underlying driver
Product parameters
| Size | 0.96 inch |
| Type | OLED |
| OLED driver chip | SSD1306 |
| Resolution | 128*64 Pixel |
| Module interface | IIC，4PIN |
| Effective display area | 21.744 x 10.864 mm |
| Module size | 27.3 x 27.8 mm |
| Field of View | >160° |
| Working temperature | -20℃~60℃ |
| storage temperature | -30℃~70℃ |
| Working voltage | 3.3V / 5V |
| power dissipation | TBD |
| Product weight | 8g |
Interface definition
| PIN | label | Pin description |
| 1 | GND | OLED GND |
| 2 | VCC | OLED VCC input(3.3V~5V) |
| 3 | SCL | OLED clock signal of IIC bus |
| 4 | SDA | OLED data signal of IIC bus |
