The LCD HDMI 7 inch 800x480 capacitive touch screen is a 7" standard display with 800 × 480 hardware resolution and a capacitive touch screen that supports up to 5-point touch. It works with Raspberry Pi, BB Black, Banana Pi and other mainstream mini PCs, and it can also be used as a general-purpose HDMI monitor.
LCD HDMI 7 Inch 800x480 Capacitive Touch Screen: Product Description
- 7" standard display, 800 × 480 Hardware resolution, Up to 1920x1080 software configuration resolution.
- Capacitive touch screen, maximum support 5-point touch.
- Support backlight control alone, the backlight can be turned off to save power.
- Support Raspberry Pi, BB Black, Banana Pi, and other mainstream mini PC.
- Can be used as a general-purpose-use HDMI monitor, for example: connect with a computer HDMI as the sub-display.
- Used as a Raspberry Pi display that supports Raspbian, Ubuntu, Kali-Linux, Kodi, win10 IOT, single-touch, free driver.
- Work as a PC monitor, supporting win7, win8, and win10 system 5 point touch (XP and older version system: single-point touch), free driver.
- CE, RoHS certification.
HDMI LCD for Raspberry Pi and PC
As an HDMI LCD for Raspberry Pi, this display connects to any HDMI output device, so you can use it as the screen for a Raspberry Pi project or as a sub-display next to your computer. If you are choosing a board for it, see the Raspberry Pi 5 4GB or browse all Raspberry Pi boards. To mount the screen, there is an acrylic screen case holder bracket for the 7 inch HDMI LCD.
800x480 HDMI LCD Display: Product Parameters
- Size: 7.0 (inch)
- Resolution: 800*480 dots
- Touch: five-point capacitive touch
- Active Area: 153.84*85.63 (mm)
- Product Size: 164.9*124.27 (mm)
- Package Size: 21115053 (mm)
- Rough Weight (Package containing): 405 (g)
- Power Dissipation: 5Vdc 0.74A
Capacitive Touch HDMI Display: Choosing the Right Screen
If you need a higher resolution, see the LCD HDMI 7 inch 1024x600 capacitive touch screen. For a bigger screen with built-in speakers, see the LCD HDMI 10 inch 1024x600 touch screen with audio speakers, or browse all LCD modules.
Frequently Asked Questions
What is the resolution of the 7 inch 800x480 HDMI LCD?
The hardware resolution is 800 × 480, and the software configuration resolution goes up to 1920x1080.
How many touch points does it support?
It is a capacitive touch screen that supports a maximum of 5-point touch.
Is the 7 inch HDMI LCD compatible with Raspberry Pi?
Yes. It supports Raspberry Pi, BB Black, Banana Pi and other mainstream mini PCs.
Which operating systems does it support?
As a Raspberry Pi display, it supports Raspbian, Ubuntu, Kali-Linux, Kodi and win10 IOT with single-touch and a free driver. As a PC monitor, it supports win7, win8 and win10 with 5-point touch and a free driver. XP and older systems get single-point touch.
What is the power consumption?
The power dissipation is 5Vdc 0.74A.
Can the backlight be turned off?
Yes. It supports backlight control alone, so the backlight can be turned off to save power.
What is the size of the screen?
It is a 7.0-inch display. The active area is 153.8485.63 mm and the product size is 164.9124.27 mm.
The LCD HDMI 7 inch 800x480 capacitive touch screen gives you a 5-point touch display for Raspberry Pi, mini PCs and any HDMI device, with a free driver and a separately controlled backlight. If you are building a touch interface for your engineering graduation projects this term, RAM Electronics offers the LCD HDMI 7 inch 800x480 capacitive touch screen in Egypt along with other LCD modules. Contact us if you need help choosing the right display for your project.
