MG995 Servo Motor 180° 10 kg.cm Metal Gears
Common model Servo 180 Degree
Internal Reference:
SERVO.MG995.180
Description:
- Item Name: MG995 Metal Gear Servo
- Dimension : 40 x 19x 43mm
- weight: about 69g
- Operating Speed: 0.17sec / 60 degrees (4.8V no load)
- Operating Speed: 0.13sec / 60 degrees (6.0V no load)
- Stall Torque: 13 kg-cm (180.5 oz-in) at 4.8V
- Stall Torque: 15 kg-cm (208.3 oz-in) at 6V
- Operation Voltage: 4.8 - 7.2Volts
- Gear Type: All Metal Gears
Features:
- Compliant with most standard receiver connectors: for Futaba, Hitec, Sanwa, GWS, etc...
- Great for trucks, boats, and Racing cars.
- Power Supply: Through External Adapter.
- Stable and Shock Proof. - Coreless Motor - Metal Gear - Double Ball Bearing -
- Connector Wire Length 300mm
Connection :
- Orange: PWM
- Red: VCC
- Brown: GND
