Electrical Specification
| Operating Voltage Range | 4.8V | 6V |
| Idle current(at stopped) | 5mA | 7mA |
| No load speed | 50 RPM | 55 RPM |
| Running current(at no load) | 160 mA | 190 mA |
| Peak stall torque | 12.5 kg.cm | 14 kg.cm |
| Stall current | 1500mA | 2000mA |
| Motor | Metal brush motor | Metal brush motor |
Mechanical Specification
- Size: 40 x 20 x 37 mm
- Gear Type: Metal gears
- Limit Angle: 360°
- Bearing: 2 Ball bearings
- Horn Gear Spline: 25T
- Horn Type: Plastic, POM
- Motor Case: Nylon & Fiberglass
- Command Signal: Pulse width modification
- Amplifier Type: Digital system
- Running Degree: 360° Continuous rotation
