XKC-Y25 NPN Intelligent Non-Contact Liquid Level Sensor

https://www.ram-e-shop.com/web/image/product.template/8131/image_1920?unique=6f1fa08

Water Level Sensor

395.00 EGP 395.0 EGP 395.00 EGP 475.00 EGP

395.00 EGP 475.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: SEN.XKCY25.NPN.LEVEL

Description

​Intelligent non-contact liquid level sensor adopts advanced signal processing technology and a high-speed signal processing chip, and it won't be influenced by container wall thickness when detecting the liquid level in an airtight container. The liquid level sensor is installed under the container (high level and low level). No need to bore a non-metallic container, easy to install. It can detect liquid levels of various toxic substances, acids, alkalis, and all kinds of liquid in high-pressure airtight containers. It can be widely used and has no special requirement for liquid medium and material of the container.

Features:

  1. A non-contacA non-contact liquid level sensor is applicable to non-metallic containers without direct contact with the liquid, not affected by scale or other impurities.
  2. Intelligent liquid level benchmark adjustment and level memory function, liquid level display mode, can achieve multi-point series connection.
  3. Electronic circuit structure rather than machinery ensures stable performance, durability, and long service life.
  4. High stability, high sensitivity, and strong anti-interference ability make sure it won't be affected by the electromagnet, specially designed to deal with power frequency interference and common mode interference.
  5. Compatible with most 5 ~ 24V power adapters.
  6. Strong compatibility through a variety of non-metallic material containers, such as plastic, glass, ceramics etc, with a 13mm or more induction distance.
  7. Testing is accurate and stable and boiling water levels can be detected. Liquid, Powder, particles can all be detected.

Specifications:

  • Material: ABS
  • Input voltage: (InVCC) DC 5 ~ 24 V
  • Current consumption: 5mA
  • High voltage output) InVCC
  • Output voltage (LOW) 0V
  • Output current: 1 ~ 100mA
  • Response time: 500mS
  • Working temperature: 0 ~ 85℃
  • Induction thickness (Sensitivity) Range: 0 ~ 20mm
  • Communication: RS485
  • Humidity: 5% to 100%
  • Waterproof: IP67
  • Size: 2.8 x 1.69 cm (Diameter x H)
