E3JK-R4M1 90~250 Vac Photoelectric Switch

https://www.ram-e-shop.com/web/image/product.template/7107/image_1920?unique=de0c2ca

IR Proximity 200cm Detection With Reflector

350.00 EGP 350.0 EGP 350.00 EGP

350.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: SEN.E3JK.R4M1.AC

Working on 90 to 250 Vac, with common (C) & normally open (NO) & normally close (NC) output. And sensor distance can be reached at 2 meters.

  • Sensor type: Photoelectric
  • Range: 0~2 meters
  • Output configuration: SPDT (Switch with 3 Pins COM, NO, NC)
  • Operation modes: DARK-ON
  • Operation mode: reflective with reflector
  • Supply voltage: 90 - 250 Vac
  • Operating current max.: 3A
  • Operating temperature: -25...55°C
  • Body material: ABS
  • Sensors feature: The reflector is provided with a sensor.
  • Body dimensions: 50 x 50 x 22mm
  • Response time: <30ms
  • Sealing IP64
