E3JK-R4M1 90~250 Vac Photoelectric Switch
IR Proximity 200cm Detection With Reflector
Internal Reference:
SEN.E3JK.R4M1.AC
Working on 90 to 250 Vac, with common (C) & normally open (NO) & normally close (NC) output. And sensor distance can be reached at 2 meters.
- Sensor type: Photoelectric
- Range: 0~2 meters
- Output configuration: SPDT (Switch with 3 Pins COM, NO, NC)
- Operation modes: DARK-ON
- Operation mode: reflective with reflector
- Supply voltage: 90 - 250 Vac
- Operating current max.: 3A
- Operating temperature: -25...55°C
- Body material: ABS
- Sensors feature: The reflector is provided with a sensor.
- Body dimensions: 50 x 50 x 22mm
- Response time: <30ms
- Sealing IP64
