Features：
• High-precision voltage and current display
• Power display
• 0.1mA current display function
• Over-current & over-temperature protection
• Dual fast charging USB port, and max single port is 24W with voltage/current 5V 3A / 12V 2A
• Output switch control
• Shutdown memory of the setting values
• Digital-potentiometer & quick-adjustment knob, which can adjust the output quickly and stably
Specifications:
|
Model |
U202 |
|
Voltage |
0-30V |
|
Current |
0-5A |
|
Load Regulation |
|
|
Voltage |
≤0.01%+2mV |
|
Current |
≤0.1%+2mA |
|
Line Regulation |
|
|
Voltage |
≤0.01%+3mV |
|
Current |
≤0.1%+3mA |
|
Setup Resolution |
|
|
Voltage |
10mV |
|
Current |
1mA |
|
Setup Accuracy(25℃+-5℃) |
|
|
Voltage |
≤0.5%+10mV |
|
Current |
≤0.5%+5mA |
|
Ripple(20-20M) |
|
|
Voltage |
≤20mVrms |
|
Current |
≤10mArms |
|
Temp. Coerricient |
|
|
Voltage |
≤150ppm |
|
Current |
≤150ppm |
|
Read Back Resolution |
|
|
Voltage |
10mV |
|
Current |
C＞0.5A 1mA |
|
C＜0.5A 0.1mA |
|
|
Read Back Temp. Coefficient |
|
|
Voltage |
≤150ppm |
|
Current |
≤150ppm |
|
Weight and Dimension |
|
|
U202 |
95mm(W)* 168mm(H)* 231mm(D) |
|
1.8kgs |
