RXN305D Linear Single Output DC Programmable Power Supply 0~30V 0~5A

https://www.ram-e-shop.com/web/image/product.template/6311/image_1920?unique=648655c PS.RXN305D

DC Adjustable Linear Power Supply
Built-in Large Transformer for Ultra-Low Output Noise

3,250.00 EGP 3250.0 EGP 3,250.00 EGP

3,250.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: PS.RXN305D

RXN305D Linear Single Output DC Programmable Power Supply 0~30V 0~5A


Product Description

The RXN-305D is a single-output linear regulated DC power supply designed for electronics laboratories, repair workshops, research and development, and general electronic testing applications.

It provides an adjustable output voltage of 0–30V DC and output current of 0–5A, with automatic switching between Constant Voltage (CV) and Constant Current (CC) operating modes.

The front panel features separate coarse and fine adjustment knobs for voltage and current, along with a dual three-digit LED display for monitoring output values. Additional functions include current preset, current limiting protection, output control, and a built-in cooling fan.

Key Features

  • Adjustable DC Output: 0–30V and 0–5A.
  • Single Output Channel: Provides one adjustable DC output.
  • Linear Regulated Design: Suitable for laboratory and electronic testing applications.
  • Automatic CV/CC Switching: Automatically operates in Constant Voltage or Constant Current mode according to load conditions.
  • Coarse and Fine Adjustment: Separate knobs for precise voltage and current adjustment.
  • Dual LED Display: Displays output voltage and current simultaneously.
  • Current Preset: Allows setting the desired current limit.
  • Current Limiting Protection: Helps protect connected circuits against excessive current.
  • Output ON/OFF Control: Dedicated power output control.
  • Built-in Cooling Fan: Helps dissipate internal heat during operation.

Technical Specifications

ParameterSpecification
SeriesRXN Series
ModelRXN-305D
Product TypeLinear Regulated DC Power Supply
Output TypeSingle Output
Output Voltage0–30V DC
Output Current0–5A
Maximum Output Power150W
Input VoltageAC 220V ±10%, 50Hz
Voltage Stabilization≤0.05% + 2mV
Load Stability (Voltage)≤0.05% + 2mV
Ripple Noise (Voltage)≤1mVrms
Current Stabilization≤0.1% + 3mA
Load Stability (Current)≤0.2% + 3mA
Display3-Digit LED Digital Display
Display Accuracy±1% ±1 digit
Display ResolutionVoltage: 0.1V / Current: 0.01A
Operating Temperature-10°C to 40°C
Operating Relative HumidityLess than 80%
Storage Temperature-10°C to 40°C
Storage Relative HumidityLess than 90%
CoolingBuilt-in Cooling Fan
Dimensions (D × W × H)278 × 126 × 155mm
Weight4.78kg

Applications

  • Electronics Testing: Supplying adjustable DC power to electronic circuits and components.
  • Laboratory Experiments: Powering prototypes and experimental circuits.
  • Repair and Maintenance: Testing and troubleshooting electronic devices and circuit boards.
  • R&D Applications: Providing a regulated DC source for circuit development.
  • Production Testing: Supplying power for electronic equipment testing and evaluation.

Package Contents

  • RXN305D Main unit
  • Power Cord (220 Vac)
  • User Manual

Frequently Asked Questions (FAQ)

1. What is the output voltage and current range of the RXN-305D?

The RXN-305D provides an adjustable output voltage from 0 to 30V DC and an output current from 0 to 5A.

2. Does the RXN-305D support Constant Voltage and Constant Current modes?

Yes. It supports both Constant Voltage (CV) and Constant Current (CC) modes, with automatic switching according to the connected load and preset current limit.

3. How can I adjust the output voltage and current?

The front panel features separate coarse and fine adjustment knobs for both voltage and current, allowing convenient and precise output adjustment.

4. Does the RXN-305D have current limiting protection?

Yes. It features current preset and current limiting protection. When the load current reaches the preset limit, the power supply automatically operates in Constant Current mode.

5. Can I turn the output ON or OFF independently?

Yes. The front panel includes a dedicated power output control button, allowing you to control the DC output without disconnecting the mains supply.

6. What type of display does the RXN-305D use?

It features a dual three-digit LED display that shows output voltage and current simultaneously. The display resolution is 0.1V for voltage and 0.01A for current.

7. Does the RXN-305D have a cooling fan?

Yes. It has a built-in cooling fan to help dissipate heat generated during operation.

8. What is the difference between the RXN-305D and a switching DC power supply?

The RXN-305D uses a linear regulated power supply design. Its specified voltage ripple noise is ≤1mVrms. Linear power supplies are commonly used in laboratory and electronics testing applications where regulated output and low ripple are important. Switching power supplies use a different conversion design and may offer advantages in size and weight, depending on the model.
