RXN3010D Linear Single Output DC Programmable Power Supply 0~30V 0~10A

https://www.ram-e-shop.com/web/image/product.template/7141/image_1920?unique=81556e7

DC Adjustable Linear Power Supply

6,000.00 EGP 6000.0 EGP 6,000.00 EGP

6,000.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: PS.RXN3010D

RXN Series Linear DC Adjustable Power Supply(300W-900W) is equipment with high stability, high reliability, low noise, its output voltage or current can be continuously adjusted, and its constant voltage and current can auto-conversion. This low-cost and universal power supply can be used in many different areas, such as electronic labs, reliability tests of electronic components, durable tests of motor and drive, test of circuit boards and electricals, test of rechargeable batteries, semiconductor aging, and replacing the batteries.

Features:

  • Single channel output
  • Front/behind output terminal
  • Internal radiator and electronic temperature control cooling fan
  • The digital meter shows the voltage and current values
  • A power supply of universal type with simplified function and highly cost-effective
  • Current limiting protection and users can set the current limiting protection point arbitrarily
  • Opposite polarity protection
  • Plastic panel of the equipment is modern, simple, and beautiful

Specification:

  • Input voltage : 220V AC ±10% 50Hz
  • Voltage output : 0 - 30V
  • Current output : 0 - 10A
  • Operating temperature : -10C - 40C
  • Constant voltage state :
    • Voltage stability : ≤0.01% + 2mV
    • Load stability : ≤0.01% + 2mV
    • Resume time: ≤100us
    • Ripple noise : ≤1mVRMS (RMS)
    • Temperture coefficient : ≤200PPM/C
  • Constant current state :
    • Current stability : ≤0.1% + 3mV
    • Load stability : ≤0.2% + 3mV
    • Ripple noise: ≤2mARMS
    • Voltage display accuracy: Three light-emitting diode: ±1%±1 unit
  • Weight: 7.26kg
  • Dimensions mm : 332×200×160

Package includes:

  • RXN3010D Main unit
  • Power Cord (220 Vac)
  • User Manual
