KXN305D-II Switching Triple Output DC Programmable Power Supply 0~30V 0~5A

https://www.ram-e-shop.com/web/image/product.template/8690/image_1920?unique=079b276

DC Adjustable Switching Mode Power Supply
Two Isolated Ground Adjustable 0-30V/0-5A outputs + One Fixed 5V/3A output

7,000.00 EGP 7000.0 EGP 7,000.00 EGP

7,000.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: PS.KXN305D.II

Introduction:

A power supply with Two isolated Ground adjustable 0-30V/0-5A outputs and One fixed 5V/3A output. The two 0-30V outputs can be combined in series to 0-60V/0-5A or parallel to 0-30V/0-10A. With this device you can power your MCU, motors or other circuits current controlled with different voltages at the same time.

The big red display shows you precisely what voltage and current you have set, while the fast-reacting current limitation protects your precious circuit against being destroyed.

Features:

  • Two adjustable 0-30V / 0-5A outputs and one fixed 5V/3A output
  • Can be combined to 0-60V/0-5A (serial) or to 0-30V/0-10A (parallel)
  • Current-limiting protection
  • Reverse polarity protection
  • Temperature controlled cooling
  • Precise voltage and current setting
  • Precise current measurement

Specification:

  • Input voltage : 220V AC ±10% 50Hz
  • Voltage output: Two adjustable 0 - 30V Outputs + Single FIxed 5V Output
  • Current output : 0 - 5A x 2
  • Operating temperature : -10C - 40C
  • Constant voltage state :
    • Voltage stability : ≤0.01% + 2mV
    • Load stability : ≤0.01% + 2mV
    • Resume time: ≤100us
    • Ripple noise : ≤1mVRMS (RMS)
    • Temperture coefficient : ≤200PPM/C
  • Constant current state :
    • Current stability : ≤0.1% + 3mV
    • Load stability : ≤0.2% + 3mV
    • Ripple noise: ≤2mARMS
    • Voltage display accuracy: Three light-emitting diode: ±1%±1 unit

Package includes:

  • KXN305D-II Main unit
  • Power Cord (220 Vac)
  • User Manual

Download

USER MANUAL
