LC2042BM Big Character Size LCD 4x20 Blue

• LC2042 (Character LCD 4x20 Big Character Size) Blue
• Display Format 20x4 Dots
• Outline Dimension 146(W)x62.5(H)x9.2(T)mm
• Visual Area 123.5×43mm
• Active Area 118.84(W)x38.47(H)mm
• Character Size 4.84x9.22mm
• Diagonal Size 5.1“
• Dot (Pixel) Size 0.92X1.1mm
• IC or Equivalent SPLC780C/HS44780/KS0066 or Equivalent
• Interface 6800 8-bit/4-bit Parallel
• Interface parallel
• Display Type STN/FSTN
• LED Backlight Color Blue
• Appearance White on Blue/Black on Yellow Green/White on Gray
• Power Supply(Typ) 5V
• Backlight Current (Typ) 70mA
• Operating Temp -20C~70C
• Storage Temperature -30C ~80C
