PN532 NFC Precise RFID IC Card Reader Module 13.56MHz
Internal Reference:
KIT.NFC.PN532.BLUE
PN532 NFC Precise RFID IC Card Reader Module 13.56MHz for Arduino & Raspberry PI
Overview
The PN532 NFC module, as its name implies, is based on PN532 chip and used for 13.56MHz near-field communication. The module is equipped with onboard antenna, thus no external antenna coil is needed. It is compatible with SPI, IIC, and UART interfaces for communication. With NFC library support for Arduino and Raspberry Pi offered by us, it is quite convenient for development of products with NFC functions.
Features
- Effective communication distance of 0~ 1 cm (depending on TAG type)
- Supports switching of SPI, IIC, and UART interface.
- Can be used for 13.56M non-contact communication
- Compatible with ISO14443 Type A and Type B standards
Specifications
- IC NXP PN532
- Operating Voltage 3.3V
- Power Supply Voltage 3.3~5.5V
- Max Supply Current 150mA
- Working Current(Standby Mode) 100mA
- Working Current(Write Mode) 120mA
- Working Current(Read Mode) 120mA
- Indicator PWR
- Interface SPI Interface, Std Raspberry Pi 20pins Interface
