4 Output Channel SSR Solid State Relay 5V Module (SKU#KIT.D14)

4 Output Channel SSR Solid State Relay 5V Module (SKU#KIT.D14)

Active at HIGH Level

300.00 EGP 300.0 EGP 300.00 EGP

300.00 EGP

This combination does not exist.

Pick up from RAM Store
Shipping: 2-3 Business Days

Internal Reference: KIT.D14.SOLID.4RELAY

Specifications

5V Omron solid state relays 240V / 2A, output with resistive fuse 240V / 2A.
Dimensions : 57x55x25 (length x width x height)
Input Power: 5VDC
Voltage: 5V
Quiescent current : 0 mA
Operating current: 12.5mA
Trigger Voltage: 3.3-5V
Trigger current: 2mA
Connection :
- DC +: positive power supply (according to the relay voltage supply)
- DC-: negative power supply
- CH1: relay module signal triggering end (Relay 1)
- CH2: relay module signal triggering end (Relay 2)
- CH3: relay module signal triggering end (Relay 3)
- CH4: relay module signal triggering end (Relay 4)
