TC-400 Fusion Splicer - Complete Set Fiber Optic Tools

https://www.ram-e-shop.com/web/image/product.template/8836/image_1920?unique=496d154

50,000.00 EGP 50000.0 EGP 50,000.00 EGP

50,000.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: FIBER.TC400

Product Parameters:

Fiber alignment 4 motors PAS core alignment
Applicable fibers Single /SMF(G.652/657), MMF(G.651), DSF(G.653), NZDSF (G.655), BI(G.657)
Cladding diameter 80-150um
Sheath diameter 100~1000um
Cleave length 8~16mm
Splice mode 100 splice modes
Typical splice time 6 sec.SM FAST
Typical splice loss 0.02dB (SM), 0.01dB (MM), 0.04dB (DSF), 0.04dB (NZDS) and 0.02dB(BI)
Return loss >>60dB
Heating mode Max.20
Heating time 16 sec.
Applicable protection sleeve 10-60mm
Splice result storage Last 20,000 splices
Splice image storage Max.800
Viewing methods 2-axis CMOS camera with 4.3 inch HD color capacitive touchscreen
Magnification Supports X / Y or both X and Y simultaneously, maximum up to 760X magnification
Interface MicroSD and USB port for software upgrade/data management
Electrode life Typical 5000 splices
Battery capacity 4000mAh battery, more than 220 times splicing and heating; Standard charging tfime:3 hours lup to 80% electric quantity in 2 hours
Power supply AC100-240V.50/60Hz
Fiber tensile test force 2N
Operating condition Altitude : 0 to 5,000m above sea level, Wind: 15m/sec
Storage condition Temperature :-10 to 50C,Humidity : 0 to 95%RH Battery: -10 to 50C
Size/weight 133W x 144D x 133H (mm) / 1.5kg (1.8kg including battery)

Kit Include:

  1. Fusion Splicer TC-400
  2. Carrying Case
  3. Fiber Cleaver
  4. Fiber Stripper
  5. Drop Cable Stripper  (TC-400&SUPER X)
  6. Cooling Tray
  7. Extra Electrodes
  8. Alcohol Bottle
  9. AC Adapter
  10. Shoulder Strap
  11. Hand Strap
  12. Air-blowing bolt
  13. Brush
  14. Knife
  15. Folding Stool
