Main Features:
- Hot air station and soldering station 2 in 1 design, saving working space.
- Hot air station: 800W, rapid heating and high efficiency.
- Soldering station: 65W, rapid heating and temperature recovery.
- LCD display, supports displaying accurate temperature & airflow.
- Built-in brushless fan, long service life and low noise.
- 3 sets shortcut air volume/temperature to simplify operations.
- Support temp lock, temp calibration function.
- Support ℃ and ℉ switchable.
- Auto standby and sleep function, conserves energy and protects equipment.
- Password-protected function to preserve settings.
- With 10~900s timing function.
- Cold air function to cool components.
Specifications:
Model: | ST-8802 | |
Handle | Soldering Iron | Hot Air Gun |
Voltage | 110VAC/220VAC ±10% 50Hz/60Hz optional | |
Fuse type | T5A(230VAC) T10A(110VAC) | |
Power | 65W | 800W |
Temperature range | 80℃~480℃/ 176℉~896℉ | 100℃~500℃/ 212℉~932℉ |
Temperature stability | ±2℃ | ±5℃ |
Air volume adjustment |  | Knob control |
Temperature adjustment | Long press to adjust 10 units at a time; Short press to adjust 1 unit at a time. | |
Standby mode | 0~60mins | it will enter into sleep mode automatically when putting the hot air gun on the holder. |
Turn off heating function | After 10 mins standby will turn off heating. | Put hot air gun on the holder for 30 mins will turn off heating. |
Shortcut temperature | 3 sets | |
Working conditions | Temperature 0-40°C, relative humidity <80% | |
Storage conditions | Temperature -20-80°C, relative humidity <80% | |
Dimension | 29.5 * 24.8 * 18.8 cm | |
Weight | 3.75KG |
Packing List：
- Rework station: ST-8802
- Hot air gun handle
- Soldering iron: 1pc
- Hot air gun holder: 1pc
- Soldering iron holder: 1pc
- Nozzles: 4pcs
- Power cord: 1pc
- Manual: 1 copy
