Basic Parameters:
- Working voltage range: DC3.5V-24V
- Maximum working current: 15mA (DC 5V)
- Load capacity: ≤10mA (DC 5V)
- Working temperature: ≤80°C
- Working Humidity: 35%~90%RH (Without frost)
- Working pressure: <1.2Mpa
Technical parameters:
- Output pulse high level: >DC4.5V (Input voltage DC: 5V)
- Output pulse low level:<DC 0.5V(Input voltage DC:5V)
- Accuracy (Flow--pulse output): Between 1-60L/Min+/-3%
- Output pulse duty cycle:50+/-10%
- Output rise time: 0.04μs
- Output fall time: 0.18μs
- Flow--pulse character: Horizontal test pulse frequency (Hz) = [5.5 Q]±3% (Q is flow L/Min)
- Insulation resistance: Beyond 100Ω(DC 500V)
Wire connection
- Red: IN-Positive (DC3.5V-24V)
- Yellow: OUT-Signal out
- Black: GND-Negative
