Character LCD 2x16 Blue 1602

Product Description

This 2x16 Character LCD Module (Blue Backlight) is a reliable and widely used display for microcontroller and embedded system projects. Giving you full flexibility to use your preferred connector type or solder wires directly based on your project requirements.

The module is fully HD44780 compatible, ensuring smooth integration with Arduino, ESP32, Raspberry Pi (via adapter), PIC, AVR, and most development platforms.

Key Features:

• Standard 2x16 character display (16 characters × 2 lines)
• Crisp white characters on a blue backlight for excellent readability
• Fully compatible with the HD44780 LCD controller
• Operates at 5V supply voltage
• Ideal for custom wiring or connector options (no pin header included)
• Compact size: 80 × 36 × 13.5 mm
• Standard 16-pin interface for easy integration
• Long-lasting, stable, and reliable for continuous operation

Pinout:

1. GND
2. VDD
3. VOP
4. RS
5. RW
6. E
   7–14. DATA (D0–D7)
7. LED+
8. LED−

Applications:

• Arduino / Microcontroller projects
• Embedded systems and instrumentation
• Robotics and automation
• DIY electronics and educational kits
• Custom display panels
