The LCD HDMI 7 inch 1024x600 capacitive touch screen is a 7-inch standard display with a five-point capacitive touchscreen. It works with Raspberry Pi, BeagleBone Black, Banana Pi and other popular mini PCs, and it can also be used as a general HDMI monitor for a computer.
LCD HDMI 7 Inch 1024x600 Capacitive Touch Screen: Product Description
- 7-inch standard display with 1024×600 hardware resolution, which can be configured in software up to 1920×1080.
- Capacitive touchscreen supporting up to five simultaneous touch points.
- The backlight can be controlled separately and turned off to save power.
- Works with Raspberry Pi, BeagleBone Black, Banana Pi, and other popular mini PCs.
- Can be used as a general HDMI monitor, such as a secondary display for a computer.
- Raspberry Pi support covers Raspbian, Ubuntu, Kali Linux, Kodi, and Windows 10 IoT, with single-touch and free drivers.
- PC support covers Windows 7, 8, and 10 with five-point touch and free drivers. Windows XP and older get single-point touch.
- CE and RoHS certified.
7 Inch HDMI Touch Screen for Raspberry Pi and PC
As a 7 inch HDMI touch screen, this display connects to any HDMI output device, so you can use it as the screen for a Raspberry Pi project or as an extra monitor next to your computer. If you are choosing a board for it, see the Raspberry Pi 5 4GB or browse all Raspberry Pi boards. To mount the screen, there is an acrylic screen case holder bracket for the 7 inch HDMI LCD.
1024x600 HDMI LCD: Product Parameters
- Size: 7.0 inches
- Resolution: 1024×600 dots
- Touch: five-point capacitive
- Active area: 154.2144 × 85.92 mm
- Product size: 164.9 × 124.27 mm
- Package size: 211 × 150 × 53 mm
- Packaged weight: 405 g
- Power dissipation: 0.62 A at 5 V at 1024×600
5-Point Capacitive Touch Screen: Choosing the Right HDMI Display
If you need a bigger screen with built-in speakers, see the LCD HDMI 10 inch 1024x600 touch screen with audio speakers. For a 7 inch TFT module with HDMI, VGA and capacitive touch, see the LMT070DAMFWA-NFD TFT LCD module from Topway, or browse all LCD modules.
Frequently Asked Questions
What is the resolution of the 7 inch HDMI LCD?
The hardware resolution is 1024×600, and it can be configured in software up to 1920×1080.
How many touch points does it support?
It is a capacitive touchscreen that supports up to five simultaneous touch points.
Is the 7 inch HDMI touch screen compatible with Raspberry Pi?
Yes. It works with Raspberry Pi, BeagleBone Black, Banana Pi and other popular mini PCs, and it supports any HDMI output device.
Which operating systems does it support?
With Raspberry Pi, it supports Raspbian, Ubuntu, Kali Linux, Kodi and Windows 10 IoT. With a PC, it supports Windows 7, 8 and 10 with five-point touch. Windows XP and older get single-point touch.
Does it need drivers?
Free drivers are available for Raspberry Pi and for PC.
Can the backlight be turned off?
Yes. The backlight can be controlled separately and turned off to save power.
What is the size of the screen?
It is a 7.0-inch display, with an active area of 154.2144 × 85.92 mm and a product size of 164.9 × 124.27 mm.
The LCD HDMI 7 inch 1024x600 capacitive touch screen gives you a five-point touch display for Raspberry Pi, mini PCs and any HDMI device, with free drivers and a separately controlled backlight. If you are building a touch interface for your engineering graduation projects this term, RAM Electronics offers the LCD HDMI 7 inch 1024x600 capacitive touch screen in Egypt along with other LCD modules. Contact us if you need help choosing the right display for your project.
