SKYRC iMAX B6 mini Professional Balance Charger/Discharger

Product Description

The SKYRC B6 mini is a high-performance, microprocessor-controlled charge and discharge station. As an upgraded version of the well-known IMAX B6, it offers increased accuracy and stability alongside new features like PC control and firmware upgrade capabilities. It supports a maximum 6A charge current and 60W charge power. Designed for versatility, it is suitable for all current battery types, featuring an integral equalizer for six-cell Lithium-Polymer (LiPo), Lithium iron phosphate (LiFe), Lithium-Ion (LiIon), and LiHV batteries. The unit also functions as a Lithium Battery Meter and Battery Internal Resistance Meter.

Key Features

• Broad Chemistry Support: Compatible with LiPo, LiIon, LiFe, LiHV, NiMH, NiCd, and Pb (Lead Acid) batteries.
• PC Control Software: Utilize the free "Charge Master" software to monitor pack voltage, view real-time graphs, and initiate or control charging via a computer.
• Terminal Voltage Control (TVC): Allows expert users to manually adjust and set the charge end voltage.
• Built-in Meters: Check total battery voltage, individual cell voltages, and internal resistance without needing extra external tools.
• Maximum Safety Functions: Equipped with an automatic charging current limit, capacity limit, processing time limit, and an adjustable temperature threshold (requires an optional probe) to prevent overcharging.
• Internal Balancer: Employs an individual-cell-voltage balancer for balancing cells safely during charging and discharging processes.
• Memory Profiles: Store and quickly load up to 10 different customized charge/discharge profiles.

Technical Specifications

Operating Instructions / How to Use

1. Connect Power: Connect the B6 mini to an 11-18V DC power source or a high-quality AC adapter.
2. Attach Charge Leads: Always connect the charge cable to the charger first to avoid short circuits. After the cable is secured to the charger, connect it to the battery.
3. Connect Balance Wire: For Lithium batteries, attach the balance wire to the balance socket on the charger, ensuring the black wire is aligned with the negative marking.
4. Set Parameters: Press the BATT/PROG button to select the battery program, choose the desired operation mode, and use the INC/DEC buttons to set the target voltage and current. Press START/ENTER to confirm your values.
5. Start Charging: Press and hold the START/ENTER button for 3 seconds to initiate the process. Verify that the cell count detected by the charger matches your setting, and press START/ENTER again to confirm and start charging.

Safety Notes & Warnings

• Never leave the charger unattended when it is connected to its power supply.
• Always place the charger and battery on a heat-resistant, non-inflammable, and nonconductive surface.
• Ensure you have selected the appropriate program and adequate current for the specific battery type being charged.
• Never attempt to charge a faulty or damaged battery, or a battery pack containing different types of cells.
• Do not connect more than one battery to the balance ports simultaneously.
