FNIRSI® SWM-10 Portable Intelligent Color Screen Spot Welding Machine
Product Description
The FNIRSI® SWM-10 Portable Intelligent Color Screen Spot Welding Machine is a compact, rechargeable spot welder designed for joining nickel strips and compatible metal sheets to battery cells and for battery pack assembly and repair.
Featuring double-pulse spot welding technology, the SWM-10 uses a preheating pulse followed by a main welding pulse to help produce stable and reliable welding points. Users can adjust the preheating time, main pulse time, interval time, and number of consecutive welding points to suit different welding conditions.
The SWM-10 delivers a maximum welding current of 1200A and supports a specified welding thickness of 0.1–0.25mm. It offers four combination adjustment levels, allowing users to select suitable welding settings for their work.
A built-in 1.8-inch color LCD screen displays operating information, including battery voltage, temperature, battery level, welding parameters, welding current, and total welding count. Intelligent monitoring and protection reminders help identify over-temperature, low-voltage, and short-circuit conditions.
In addition to spot welding, the SWM-10 functions as a portable power bank with a built-in 5000mAh lithium battery, supporting 5V/2.1A charging and discharging through its charging and USB-A output interfaces.
Its portable design makes it suitable for battery pack assembly, battery maintenance, DIY electronics projects, and workshop applications.
Key Features
- Double-Pulse Spot Welding Technology: Uses preheating and main welding pulses to help achieve stable and firm welding connections.
- Maximum Welding Current of 1200A: Provides high-current output for spot welding compatible metal strips and sheets.
- Adjustable Welding Thickness: Supports a specified welding thickness range of 0.1–0.25mm.
- Four Combination Adjustment Levels: Provides four adjustable gear combinations for different welding conditions.
- 1.8-Inch Color LCD: Displays welding parameters, battery voltage, temperature, battery level, welding current, and welding count.
- Adjustable Preheating Time: Controls the initial pulse used to preheat the welding electrodes and workpiece.
- Adjustable Main Pulse Time: Allows users to adjust the main welding pulse according to the material and welding requirements.
- Adjustable Interval Time: Controls the time interval between welding pulses.
- Consecutive Welding Points: Adjustable number of welding operations after the electrodes make contact, helping reinforce welding connections.
- Intelligent Temperature Monitoring: Monitors operating temperature and provides over-temperature warnings.
- Multiple Protection Reminders: Includes over-temperature, low-voltage, and short-circuit warnings.
- Built-in 5000mAh Battery: Provides rechargeable portable operation.
- Power Bank Function: Can charge compatible USB-powered devices through its USB-A output.
- USB Type-C Charging: Supports 5V/2.1A charging.
- Portable Handheld Design: Convenient for battery pack assembly, maintenance, and DIY applications.
- Welding Pen Holder: Provides dedicated storage for the welding pens on the device.
Technical Specifications
General Specifications
| Parameter | Specification |
|---|---|
| Brand | FNIRSI |
| Model | SWM-10 |
| Product Type | Portable Intelligent Spot Welding Machine |
| Display | 1.8-inch FFT High-Definition Color LCD |
| Welding Technology | Double-Pulse Spot Welding |
| Maximum Welding Current | 1200A |
| Welding Thickness | 0.1–0.25mm |
| Adjustment Levels | 4 Combination Adjustment Levels |
| Battery Capacity | 5000mAh |
| Battery Type | Lithium Battery |
| Charging Interface | USB Type-C |
| Charging Input | 5V / 2.1A |
| USB Output | 5V / 2.1A |
| Power Bank Function | Yes |
| Dimensions | 155 × 82 × 28mm |
Welding Specifications
| Parameter | Specification |
|---|---|
| Maximum Welding Current | 1200A |
| Specified Welding Thickness | 0.1–0.25mm |
| Welding Technology | Double-Pulse |
| Preheating Pulse | Adjustable |
| Main Welding Pulse | Adjustable |
| Pulse Interval | Adjustable |
| Consecutive Welding Points | Adjustable |
| Default Consecutive Welding Points | 1 |
| Welding Adjustment | 4 Combination Levels |
| Welding Materials | Nickel Sheet, Iron Sheet, Stainless Steel Sheet |
Battery and Power Bank Specifications
| Parameter | Specification |
|---|---|
| Battery Capacity | 5000mAh |
| Charging Input | 5V / 2.1A |
| USB Discharging Output | 5V / 2.1A |
| Charging Port | USB Type-C |
| Output Port | USB-A |
| Power Bank Function | Supported |
Display and Protection Functions
| Function | Description |
|---|---|
| Battery Monitoring | Displays battery voltage and remaining capacity |
| Temperature Monitoring | Displays operating temperature |
| Welding Current Display | Shows welding current |
| Welding Counter | Displays total welding count since startup |
| Preheating Time | Adjustable |
| Main Pulse Time | Adjustable |
| Interval Time | Adjustable |
| Consecutive Welding Points | Adjustable |
| Over-Temperature Warning | Supported |
| Low-Voltage Warning | Supported |
| Short-Circuit Warning | Supported |
| Welding Status Indicator | Supported |
Applications
- Battery Pack Assembly: Spot welding nickel strips onto compatible rechargeable battery cells when assembling battery packs.
- 18650 Battery Pack Projects: Suitable for DIY battery pack assembly using compatible nickel strips and appropriate welding settings.
- Battery Repair and Maintenance: Useful for repair work involving battery connections and nickel strip replacement.
- DIY Electronics Projects: Suitable for hobbyists and electronics makers working on rechargeable battery-powered projects.
- Nickel Strip Welding: Designed for spot welding compatible nickel sheets and strips.
- Metal Sheet Spot Welding: Supports the specified iron and stainless steel sheet materials within the applicable welding limits.
- Portable Workshop Use: Its built-in rechargeable battery allows operation without requiring a continuous external power connection.
- Battery Pack Prototyping: Useful for educational projects and small-scale battery assembly work.
Frequently Asked Questions (FAQ)
1. What is the maximum welding current of the FNIRSI SWM-10?
The FNIRSI SWM-10 has a specified maximum welding current of 1200A, providing high-current output for compatible spot welding applications.
2. What is the maximum welding thickness supported by the SWM-10?
The specified welding thickness range is 0.1–0.25mm. Actual welding results depend on the material, surface condition, electrode contact, battery charge level, and selected welding parameters.
3. What materials can the FNIRSI SWM-10 weld?
The operating manual specifies nickel sheets, iron sheets, and stainless steel sheets. The manufacturer's product page also lists aluminum sheets, but this material is not included in the manual's English welding-material specification. Please verify aluminum compatibility with FNIRSI before relying on it.
4. What is double-pulse spot welding technology?
Double-pulse welding uses two stages: a preheating pulse that briefly heats the electrode contact area, followed by a main high-energy pulse that produces the welding connection. The SWM-10 allows adjustment of the pulse settings to help achieve suitable welding results.
5. Can I adjust the welding parameters?
Yes. Users can adjust the preheating time, main pulse time, interval time, and number of consecutive welding points. The device also provides four combination adjustment levels.
6. Does the SWM-10 have a built-in battery?
Yes. It features a built-in 5000mAh rechargeable lithium battery, allowing portable operation without a continuous external power supply.
7. Can the FNIRSI SWM-10 be used as a power bank?
Yes. The device includes a power bank function with a USB-A output rated at 5V/2.1A for charging compatible USB-powered devices.
8. Does the SWM-10 provide protection and warning functions?
Yes. The device monitors operating conditions and provides warnings for over-temperature, low battery voltage, and short-circuit conditions. Its display also shows battery voltage, temperature, welding current, and welding count.
