LED SMD 3W High Power White
6000-6500K
With Heat Shink
مرجع داخلي:
LED.SMD.3W
High-intensity warm light LED module. 3W LED is mounted to a style aluminum heat sink with a heat sink compound between the LED and the heat sink. These are the same LEDs found in many high-intensity LED flashlights and lanterns. Solder your connection wires to the silver rectangles marked with "+" signs for positive and "-" signs for negative.
NOTE: The star heat sink on this LED cannot fully dissipate a full 3W of heat. Therefore to drive this LED at its highest power for extended periods of time you will need to add additional heat sinking.
- Output Intensity 180-210 Lumens
- White 6000-6500K
- DC Forward Voltage 3.4 V Typical
- DC Forward Current Maximum 750mA
- Beam Angle 135°
