  2. STM32F446RET6 NUCLEO-F446RE ARM STM32 Minimum System Development Board

STM32F446RET6 NUCLEO-F446RE ARM STM32 Minimum System Development Board

https://www.ram-e-shop.com/web/image/product.template/9248/image_1920?unique=8184516

2,250.00 EGP 2250.0 EGP 2,250.00 EGP

2,250.00 EGP

Not Available For Sale

هذه التركيبة غير موجودة.

تواصل معنا

 متاح للشراء مباشرة من فرع رام للالكترونيات
 متاح خدمة الشحن للمنتج خلال 2-3 ايام عمل

مرجع داخلي: KIT.STM32F446RET6

Product Overview:

The STM32 Nucleo-F446RE is a powerful and versatile development board featuring the STM32F446RET6 microcontroller. It provides an affordable and flexible platform for developers to design, prototype, and test embedded applications. With compatibility for Arduino™ Uno V3 and ST morpho headers, it allows for easy expansion and integration with various modules and shields. The on-board ST-LINK/V2-1 debugger/programmer simplifies the development process without the need for external tools

Key Features:

  • Microcontroller: STM32F446RET6
    • Core: ARM® 32-bit Cortex®-M4 with FPU
    • Operating Frequency: Up to 180 MHz
    • Flash Memory: 512 KB
    • SRAM: 128 KB
    • Package: LQFP64
  • Integrated Debugger/Programmer: ST-LINK/V2-1
    • USB re-enumeration capability: mass storage, Virtual COM port, and debug port
  • Connectivity:
    • USB Interface: USB 2.0 Full Speed
    • Communication Interfaces:
      • USART/UART: 6
      • SPI: 3
      • I2C: 3
      • CAN: 2
      • SDIO: 1
  • Analog Features:
    • ADC: 3 × 12-bit ADCs with up to 16 channels
    • DAC: 2 × 12-bit DACs
  • Timers:
    • 17 timers, including advanced-control, general-purpose, and basic timers
  • GPIO: Up to 50 I/O ports with interrupt capability
  • Power Supply:
    • USB VBUS (5V)
    • External sources: 3.3V, 5V, 7V to 12V
  • Operating Voltage: 1.7V to 3.6V
  • Expansion Connectors:
    • Arduino™ Uno V3 compatibility
    • ST morpho extension pin headers for full access to all STM32 I/Os
  • On-board Features:
    • 1 user LED (LD2)
    • 1 user push-button
    • 1 reset push-button
    • 32.768 kHz crystal oscillator for RTC

Software Support:

  • Comprehensive free software libraries and examples are available with the STM32Cube MCU Package
  • Compatible with various Integrated Development Environments (IDEs), including:
    • IAR Embedded Workbench
    • Keil MDK
    • STM32CubeIDE
    • ARM® mbed™ online resources

Applications:

  • Embedded system prototyping
  • IoT device development
  • Industrial control systems
  • Consumer electronics
  • Educational purposes
