ZY-KPWM PWM Signal Generator 1-Channel Module 1Hz-150KHz Input DC 3.3-30V

ZY-KPWM Pulse Frequency Signal Generator Adjustable Frequency and Duty Cycle Module (1Hz–150kHz, 3.3V–30V)

The ZY-KPWM Pulse Frequency Signal Generator is a versatile and compact tool for generating precise PWM signals. Designed for a wide range of applications, this module offers flexibility, ease of use, and excellent performance, making it an ideal choice for hobbyists, educators, and professionals.

Key Features:

• Wide Frequency Range:
  Adjustable from 1Hz to 150kHz, with high accuracy for diverse applications.
• Flexible Duty Cycle Adjustment:
  Easily adjust the duty cycle from 0% to 100% to suit your needs.
• Broad Input Voltage Compatibility:
  Operates on a DC input voltage between 3.3V and 30V, compatible with most power sources.
• User-Friendly Digital Control:
  Features a 7-segment LED display for real-time visualization of frequency and duty cycle settings. Adjust settings conveniently using onboard buttons.
• Compact and Durable:
  Lightweight and easy to integrate into your projects.

Applications:

1. DC Motor Speed Control:
   Generate PWM signals for precise motor control in robotics and industrial applications.
2. LED Dimming:
   Achieve seamless brightness control by varying the duty cycle.
3. Circuit Testing and Debugging:
   Use as a reliable signal source for testing and analyzing electronic components and systems.
4. Educational Tool:
   Perfect for teaching and learning PWM concepts and signal generation.

Specifications:

• Frequency Range: 1Hz–150kHz (divided into multiple precise ranges).
• Duty Cycle Range: 0%–100%.
• Input Voltage: 3.3V–30V DC.
• Output: Digital PWM signal with adjustable parameters.

How to Use:

1. Connect a DC power supply within the specified range.
2. Use the buttons to set the desired frequency (displayed on the LED).
3. Adjust the duty cycle to match your application requirements.
4. Connect the output to your device, circuit, or motor.
